JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
10,00-20 151/-3 281 335 27 32 R18 B3 10 100201
10,00-20 210/-3 281 335 27 10 100206
10,00-20 151/-3 281 335 26 10 100207
10,00-20 161/-4 281 335 26 10 100214
10,00-20 0 281 335 26 10 100218
10,00-20 214/-3 281 335 26 10 100222
10,00-20 214/-3 281 335 27 32 R18 B3 10 100223
10,00V-20 216/+3 281 335 26 10 100225
10,00-20 206/+-3 281 335 26 10 100233
10,00V-20 120/+-2 281 335 26 10 100236
10,00V-20 68/+-2 281 335 26 10 100237
10,00V-20 161/+-2 281 335 26 10 100239
10,00-20 0 281 335 26 32 R18 A33 10 100245
10,00V-20 90/+-2 281 335 26 10 100252
10,00V-20 216/+-2 281 335 26 10 100256
10,00-20 120/+-2 281 335 26 10 100258
10,00-20 132/+-2 281 335 27 32 R18 B3 10 100266
10,00W-20 120/+-2 221 275 24 8 100278
10,00V-20 114/+-2 281 335 26 10 100281
10,00W-20 205/+4 281 335 27 32 R18 B3 10 100283
10,00W-20 95/+-2 281 335 26 10 100284
10,00W-20 101/+-2 281 335 26 10 100291
10,00W-20 121/+-2 281 335 27 32 R18 B3 10 100294
10,00W-20 120/+-2 281 335 26 10 100298
10,00W-20 120/+-2 281 335 26 10 100300
10,00W-20 95/+-2 281 335 26 10 100302
10,00W-20 95/+-2 281 335 26 10 100303
10,00W-20 114/+3 281 335 26 10 100304
10,00W-20 114/+3 281 335 26 10 100305
10,00W-20 121/+-2 281 335 26 32 R18 B33 10 100306
10,00W-20 121/+-2 281 335 26 10 100307
10,00V-20 120/+-2 281 335 26 10 100313
10,00V-20 0 281 335 26 10 100319
10,00W-20 76/+-2 281 335 26 10 100323
10,00W-20 114/+-2 281 335 26 10 100325
10,00W-20 114/+-2 281 335 26 10 100327
10,00W-20 216/+-2 281 335 26 10 100329
10,00W-20 216,5/+-2 281 335 26 10 100333
10,00-20 212/+-2 281 335 26 10 100334
10,00W-20 45/+-2 281 335 26 10 100335
10,00V-20 70/+-2 221 275 24 8 100341
10,00V-20 89/+-2 281 335 26 10 100342
10,00V-20 114/+-2 281 335 26 10 100344
10,00V-20 122/+-2 281 335 26 10 100345
10,00W-20 114/+-2 281 335 26 10 100351
10,00W-20 148/+-2 281 335 26 10 100354
10,00V-20 120/+-2 221 275 24 8 100357
10,00W-20 114/+-2 281 335 26 10 100365
10,00W-20 120/+-2 281 335 26 10 100367
10,00W-20 eksi 35/+-2 281 335 26 10 100369
10,00V-20 120/+-2 281 335 26 10 100375
10,00V-20 120/+-2 221 275 26 8 100380
10,00V-20 214/-3 281 335 26 10 100381
10,00-20 120/-3 281 335 26 10 100382
11,00V-20 80/+-2 221 260 26 8 110225
11,00-20 SDC 120/+4 221 275 24 8 110226
11,00-20 SDC 120/+4 221 275 26 8 110229
11,00-20 SDC 95/+-2 161 205 21.5 6 110230
11,00-20 SDC 120/+2 221 275 24 8 110232
11,00V-20 85/+-2 281 335 26 10 110233
11,00-20 SDC 120/+2 221 275 24 8 110236
6,0-20 140/+-2 221 275 24 8 60258
6,0-20 135/+4 152.4 203.2 31.7 37 90 B- 5 60261
6,5-20 150/+-2 221 275 27 32 R18 B3 8 65250
6,5-20 145/+4 221 275 26 32 R18 B33 8 65259
6,5-20 153/+-2 165.1 222.25 31.7 37 90 B- 6 65267
6,5-20 0 161 205 21.5 27 R16 A2 6 65268
7,0-20 157/+3 221 275 25.4 31.5 80 B17 8 70201
7,0-20 153/+3 281 335 26 10 70203
7,0-20 153/+4 281 335 27 32 R18 B3 10 70204
7,5-20 165/+4 281 335 26 10 75202
7,5-20 165/+4 281 335 27 32 R18 B3 10 75203
7,5-20 165/+4 281 335 26 10 75400
7,5-20 166/+-2 281 335 26 10 75417
7,5-20 165/+4 281 335 26 31.5 80 A37 10 75431
8,0-20 172/+4 281 335 26 10 80201
8,0-20 172/+4 281 335 27 32 R18 B3 10 80221
8,0-20 172/+4 281 335 26 10 80400
8,5-20 180/-3 281 335 27 32 R18 B3 10 85202
8,5-20 172/+4 281 335 27 32 R18 B3 10 85204
8,5-20 180/+-2 281 335 26 10 85232
8,5-20 130/+-2 281 335 26 10 85234
8,5-20 180/+2 281 335 26 10 85400
8,5-20 180/+2 281 335 27 32 R18 B3 10 85401
8,5-20 180/-3 281 335 26 10 85406
8,5-20 172/+3 281 335 26 10 85412
8,5-20 174/+-2 281 335 26 10 85416
8,5-20 180/-2 281 335 26 10 85423
8,5-20 174/+-2 281 335 26 10 85428
8,5-20 175/+-2 281 335 26 10 85602
8,5-20 105/+-2 221 275 24 8 85603
8,5-20 190/+-2 281 335 26 10 85610
8,5-20 185/-1,5 281 335 26 10 85626
8,5-20 175/+-2 281 335 26 10 85629
8,5-20 185/+-2 281 335 8x27 / 2x28 10 85654
8,5-20 171/+-2 281 335 26 10 85659
9,0-20 175/+4 170.1 225 14.5 10 90203
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
19,5X11,75 0 221 275 26 8 111950
19,5X11,75 0 221 275 27 32 R18 B3 8 111960
19,5X11,75 120/+-2 281 335 26 10 111967
19,5X11,75 kul.140/+-1,5 281 335 23.8 38.1 R22,2 A- 10 111968
19,5X11,75 120/+-2 281 335 26 10 111972
19,5X11,75 0 221 275 21.5 27 R16 A2 8 111975
19,5X11,75 0 221 275 26 8 111985
19,5X11,75 0 281 335 26 10 111986
19,5X11,75 120/+-2 281 335 26 10 111987
19,5X11,75 0 176 225 27 32 R18 B3 10 111992
19,5X11,75 eksi 49,5/+-2 221 275 20.5 8 112007
19,5X11,75 0 161 205 21.5 27 R16 A2 6 112011
19,5X11,75 0 161 205 21.5 6 112024
19,5X14,00 0 221 275 24 8 141950
19,5X14,00 0 221 275 26 8 141951
19,5X14,00 0 281 335 27 32 R18 B3 10 141952
19,5X14,00 0 281 335 26 10 141953
19,5X14,00 0 221 275 21.5 27 R16 A2 8 141954
19,5X14,00 0 281 335 26 32 R18 B33 10 141958
19,5X14,00 eksi 60/+-2 281 335 27 32 R18 B3 10 141960
19,5X14,00 120/+-2 281 335 26 10 141970
19,5X14,00 0 281 335 26 10 141971
19,5X14,00 125/+-2 281 335 26 10 141972
19,5X14,00 0 221 275 26 8 141975
19,5X14,00 0 221 275 26 8 141977
19,5X14,00 0 281 335 26 10 141992
19,5X14,00 120/-2 281 335 26 10 141994
19,5X14,00 0 281 335 26 32 R18 B33 10 142005
19,5X14,00 120/+-2 281 335 26 10 142010
19,5X14,00 120/+-2 221 275 21.5 27 R16 A2 8 142045
19,5X14,00 eksi 40/+-2 281 335 24 29 R16 B- 10 142063
19,5X14,00 eksi 53,5/+-2 222.3 275 20.6 8 142072
19,5X14,00 0 221 275 27 32 R18 A3 8 142073
19,5X14,00 120/-3 281 335 26 10 142091
19,5X6,00 135/-3 164 222.25 32.5 37 R22 B- 6 600190
19,5X6,00 129/+4 121.4 165.1 15.8 8 600204
19,5X6,00 135/-3 140.7 184.15 14.2 6 600207
19,5X6,00 129/+4 125.2 170 14.2 8 600211
19,5X6,00 129/+4 169.8 225.4 14.2 10 600212
19,5X6,00 129/+4 149.2 203.2 32.15 37 R22,2 B5 5 600215
19,5X6,00 129/+4 142.2 200 15.9 8 600216
19,5X6,75 145/+-3 221 275 27 32 R18 B3 8 675189
19,5X6,75 145/+-3 164 222.25 32.5 37 R22 B- 6 675190
19,5X6,75 145/+-3 164 222.25 32.5 37.5 R22 B- 6 675191
19,5X6,75 145/+-3 221 275 26 32 R18 B33 8 675193
19,5X6,75 145/+-3 176 225 26 32 R18 B33 10 675197
19,5X6,75 145/+-2 134/+-2 221 275 24 8 675198
19,5X6,75 0 125.1 170 16.2 8 675503
19,5X6,75 145/+-2 221 275 24 8 675504
19,5X6,75 143/+3 132/+3 221 275 25 8 675507
19,5X6,75 145/+-2 121.4 165.1 15.8 8 675509
19,5X6,75 145/+-2 221 275 24 8 675510
19,5X6,75 145/+-3 164 222.25 24 6 675511
19,5X6,75 28/+-2 117.6 152.4 15 20.5 90 B- 6 675512
19,5X6,75 kul.117,5/-3 152.4 203.2 16.6 22.8 90 A- 8 675514
19,5X6,75 28/+-2 117.6 152.4 15 20.5 90 B- 6 675516
19,5X6,75 28/+-2 117.6 152.4 15 20.5 90 B- 6 675517
19,5X6,75 2,5/+-2 120.6 165.1 16 19.8 60 B14 8 675520
19,5X6,75 18/+-2 152.9 203.2 16.6 23 90 B- 8 675521
19,5X6,75 145/+-2 120.9 165.1 15.8 8 675522
19,5X6,75 28/+-2 117.6 152.4 15 20.5 90 B- 6 675523
19,5X6,75 15/+-2 229.5 273 16.7 22 90 A- 8 675524
19,5X7,50 150/+-2 176 225 26 10 750190
19,5X7,50 156/+-2 176 225 27 32 R18 B3 10 750191
19,5X7,50 150/+-2 176 225 26 32 R18 B33 10 750192
19,5X7,50 156/+-2 221 275 21.5 27 R16 B2 8 750193
19,5X7,50 156/+-2 221 275 27 32 R18 B3 8 750196
19,5X7,50 156/+-2 221 275 26 8 750305
19,5X7,50 156/+-2 221 275 24 8 750310
19,5X7,50 156/+-2 221 275 26 32 R18 B33 8 750315
19,5X7,50 0 161 205 21.5 27 R16 A2 6 750316
19,5X7,50 156/+-2 176 225 26 32 R18 B33 10 750318
19,5X7,50 148/+2 221 275 26 32 R18 B33 8 750323
19,5X7,50 156/+-2 221 275 24 8 750325
19,5X7,50 156/+-2 221 275 26 8 750336
19,5X7,50 156/+-2 221 275 25.4 31.5 80 B17 8 750338
19,5X7,50 0 176 225 25.4 31.5 80 B17 10 750340
19,5X7,50 0 221 275 27 32 R18 A3 8 750349
19,5X7,50 151/+-2 176 225 26 32 R18 A33 10 750352
19,5X7,50 156/+-2 221 275 24 8 750357
19,5X7,50 162,5/+-2 220 285.75 26 10 750362
19,5X7,50 148/+-2 221 275 24 8 750363
19,5X7,50 138/+4 221 275 24 8 750366
19,5X7,50 0 221 275 21.5 27 R16 A2 8 750377
19,5X7,50 137/+-2 281 335 26 10 750384
19,5X7,50 115/+-2 161 205 21 6 750404
19,5X7,50 139/+-2 221 275 21.5 27 R16 B2 8 750405
19,5X7,50 139/+-2 221 275 26 8 750406
19,5X7,50 156/+-2 221 275 21.5 27 R16 B2 8 750410
19,5X8,25 164/+-3 176 225 26 10 825102
19,5X8,25 164/+-3 221 275 26 8 825110
19,5X8,25 164/+-3 221 275 24 8 825111
19,5X8,25 0 221 275 21.5 27 R16 A2 8 825118
19,5X8,25 0 161 205 21.5 27 R16 A2 6 825120
19,5X8,25 160/+-2 176 225 26 32 R18 B33 10 825132
19,5X8,25 164/+-2 221 275 27 32 R18 B3 8 825139
19,5X8,25 66/+3 221 275 26 8 825142
19,5X8,25 164/+-3 221 275 26 32 R18 B33 8 825143
19,5X8,25 0 176 225 26 10 825155
19,5X8,25 0 161 205 21.5 27 R16 A2 6 825161
19,5X8,25 160/+-2 176 225 26 10 825163
19,5X8,25 0 161 205 21.5 27 R16 A2 6 825300
19,5X8,25 146/+-2 221 275 21.5 8 825302
19,5X8,25 0 150 203.2 21.5 27 R16 A2 5 825308
19,5X8,25 66/+3 176 225 26 10 825313
19,5X8,25 147/+3 221 275 26 8 825319
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
22,5X11,75 0 281 335 26 10 117564
22,5X11,75 45/+-2 281 335 26 10 117585
22,5X11,75 kul.117/+-1 281 335 26 10 117596
22,5X11,75 135/+-2 281 335 26 10 117599
22,5X11,75 135/+-2 281 335 26 10 117637
22,5X11,75 135/+-3 281 335 26 10 117638
22,5X11,75 0 281 335 25.4 31.5 80 B17 10 117640
22,5X11,75 120/+-2 281 335 25.4 31.5 80 B17 10 117641
22,5X11,75 120/+-2 281 335 26 32 R18 B33 10 117652
22,5X11,75 0 221 275 27 32 R18 A3 8 117656
22,5X11,75 120/+-2 281 335 26 10 117665
22,5X11,75 0 281 335 26 10 117667
22,5X11,75 50/+-2 281 335 26 10 117668
22,5X11,75 0 281 335 26 32 R18 A33 10 117671
22,5X11,75 0 221 275 26 32 R18 B33 8 117676
22,5X11,75 eksi 70/+-2 281 335 27 32 R18 A3 10 117723
22,5X11,75 eksi 45/+-2 281 335 26 10 117734
22,5X11,75 120/+-2 281 335 26 10 117744
22,5X11,75 0 281 335 27 32 R18 A3 10 117753
22,5X11,75 eksi 6/+-2 281 335 26 10 117755
22,5X11,75 120/+-2 281 335 26 10 117756
22,5X11,75 135/+-2 281 335 26 32 R18 A33 10 117762
22,5X11,75 0 281 335 26 10 117767
22,5X11,75 0/+-2 161 205 21.5 27 R16 A2 6 117773
22,5X12,25 kul.160,5/+-1,5 290 335 21.5 36.7 R22,2 A- 5 122511
22,5X12,25 120,5/+-2 220 285.75 26 10 122512
22,5X12,25 0 220 285.75 26 10 122513
22,5X12,25 101,5+-2 220 285.75 26 10 122514
22,5X12,25 101,5/+-2 221.5 285.75 32.5 37 R22,2 B- 10 122517
22,5X12,25 120,5/+-2 221.5 285.75 32.5 37 R22,2 B- 10 122518
22,5X12,25 118/+4 220 285.75 26 10 122519
22,5X12,25 eksi 29,5/+-2 281 335 22.2 10 122520
22,5X12,25 16/+-2 221.5 285.75 32.5 37.5 R22,2 B- 10 122523
22,5X12,25 221,5/+-2 221 275 23 8 122526
22,5X12,25 50/+2 221 275 23 8 122527
22,5X12,25 eksi 15/+-2 281 335 22 10 122529
22,5X13,00 0 281 335 26 10 130202
22,5X13,00 0 281 335 27 32 R18 A3 10 130205
22,5X13,00 0 281 335 26 10 130207
22,5X13,00 0 281 335 26 32 R18 A33 10 130214
22,5X13,00 0 221 275 21.5 27 R16 A2 8 130216
22,5X13,00 133,5/+-2 220 285.75 26 10 130257
22,5X13,00 120/+-2 281 335 26 10 130261
22,5X13,00 66,5/+-2 221.5 285.75 32.5 37.5 R22,2 B- 10 130265
22,5X13,00 40/+-2 281 335 26 32 R18 B33 10 130273
22,5X13,00 0 281 335 26 10 130292
22,5X13,00 0 281.5 335 24 36 R22,2 A- 10 130303
22,5X13,00 0 281 335 26 10 130311
22,5X13,00 120/+-2 281 335 26 10 130315
22,5X13,00 0 281 335 26 10 130319
22,5X14,00 0 281 335 27 32 R18 B3 10 140201
22,5X14,00 0 281 335 26 10 140202
22,5X14,00 0 281 335 26 32 R18 B33 10 140203
22,5X14,00 0 281 335 26 10 140206
22,5X14,00 180/+-3 281 335 27 32 R18 B3 10 140228
22,5X14,00 0 281 335 25.4 31.5 80 B17 10 140233
22,5X14,00 0 281 335 27 32 R18 A3 10 140234
22,5X14,00 eksi 51/+-2 220 285.75 26 10 140248
22,5X14,00 120/+-2 281 335 27 32 R18 B3 10 140254
22,5X14,00 120/+-2 281 335 26 10 140264
22,5X14,00 eksi 90/+-2 281 335 26 32 R18 A33 10 140271
22,5X14,00 120/+-2 281 335 26 10 140286
22,5X14,00 120/+-2 281 335 26 10 140292
22,5X14,00 0 281 335 26 10 140305
22,5X14,00 90/+2-1 140900
22,5X15,00 120/+-2 281 335 26 10 150201
22,5X15,00 0 281 335 26 10 150202
22,5X15,00 0 281 335 27 32 R18 A3 10 150207
22,5X15,00 155/+-2 281 335 26 10 150210
22,5X15,00 50/+-2 281 335 27 32 R18 A3 10 150211
22,5X6,75 144/+-2 221 275 26 8 675205
22,5X6,75 144/+-2 281 335 26 10 675214
22,5X6,75 144/+-2 165.1 222.25 31.7 37.5 R22,2 B- 6 675215
22,5X6,75 144/+-2 158.8 222.25 17.4 10 675216
22,5X6,75 144/+-2 152.4 203.2 31.7 37.5 R22,2 B- 5 675217
22,5X6,75 145/+-2 221 275 25 8 675218
22,5X6,75 144/+-2 40 675219
22,5X6,75 146/-2 149.2 203.2 32.1 37.5 R22,2 B- 5 675220
22,5X6,75 134/-2 222.25 285.75 31.75 37.5 R22,2 B- 10 675221
22,5X6,75 153/+2 141/+2 221 275 24 8 675223
22,5X7,50 153/+4 281 335 27 32 R18 B3 10 750203
22,5X7,50 153/+4 221 275 21.5 27 R16 B2 8 750204
22,5X7,50 153/+4 281 335 25.4 31.5 80 B17 10 750205
22,5X7,50 153/+4 281 335 26 10 750206
22,5X7,50 161/-4 281 335 26 10 750207
22,5X7,50 153/+4 221 275 26 8 750216
22,5X7,50 163,5/+-2 220 285.75 26 10 750221
22,5X7,50 163,5/+-2 220 285.75 26 10 750222
22,5X7,50 160/+-2 281 335 26 10 750237
22,5X7,50 153/+4 221 275 25.4 31.5 80 B17 8 750240
22,5X7,50 88/-2 281 335 26 10 750241
22,5X7,50 165/+-2 281 335 26 32 R18 B33 10 750242
22,5X7,50 160/+-2 281 335 26 32 R18 B33 10 750248
22,5X7,50 153/+3 281 335 26 10 750261
22,5X7,50 160/+-2 221 275 24 8 750265
22,5X7,50 153/+-2 281 335 26 10 750294
22,5X7,50 115/-2 750900
22,5X8,25 165/+4 281 335 27 32 R18 B3 10 825201
22,5X8,25 165/+4 281 335 26 10 825202
22,5X8,25 165/+4 281 335 25.4 31.5 80 B17 10 825203
22,5X8,25 0 281 335 26 10 825206
22,5X8,25 165/+4 221 285 32.5 37 R22 B- 8 825207
22,5X8,25 168/+-2 220 285.75 26 10 825211
22,5X8,25 165/+4 221 275 27 32 R18 B3 8 825226
22,5X8,25 170/+-2 281 335 26 10 825228
22,5X8,25 170/+-2 221 285 32.15 37 R22,2 B5 8 825232
22,5X8,25 168/+-2 221.6 285.75 31.8 37 R22,2 B- 10 825252
22,5X8,25 168/+-2 220 285.75 26 10 825262
22,5X8,25 165/+-2 281 335 26 10 825266
22,5X8,25 165/+-2 281 335 27 32 R18 B3 10 825269
22,5X8,25 168/+-2 220 285.75 26 10 825272
22,5X8,25 168/+-2 220 285.75 26 10 825279
22,5X8,25 168/+-2 220 285.75 26 10 825282
22,5X8,25 kul.140/+3 221 285.75 25.4 10 825290
22,5X8,25 165/+1,5 281 335 26 10 825295
22,5X8,25 165/+-2 281 335 26 10 825299
22,5X8,25 65/+-2 221 275 26 8 825505
22,5X8,25 168/+-2 281 335 26 10 825506
22,5X8,25 168/+-2 221 275 26 8 825508
22,5X8,25 165/+4 281 335 26 10 825515
22,5X8,25 157/+-2 221 275 21.5 27 R16 A2 8 825521
22,5X8,25 128/+3 221.5 285.75 31.7 37.7 R22,2 A- 10 825522
22,5X8,25 88/-2 281 335 26 10 825529
22,5X8,25 0/-3 281 335 26 10 825532
22,5X8,25 120/+-2 825900
22,5X8,25 120/+-2 825902
22,5X9,00 175/+4 281 335 27 32 R18 B3 10 900201
22,5X9,00 175/+4 281 335 26 10 900202
22,5X9,00 175/+4 281 335 25.4 31.5 80 B17 10 900206
22,5X9,00 175/+4 281 335 26 10 900249
22,5X9,00 175/+4 281 335 27 32 R18 B3 10 900250
22,5X9,00 178/+-2 221.5 285.75 32.5 37 R22,2 B- 10 900251
22,5X9,00 0 221 275 21.5 27 R16 A2 8 900252
22,5X9,00 175/+4 281 335 26 10 900258
22,5X9,00 133,5/+-2 220 285.75 28.5 10 900275
22,5X9,00 0 281 335 26 32 R18 B33 10 900278
22,5X9,00 118/+-2 281 335 26 10 900283
22,5X9,00 175/+-2 281 335 26 32 R18 B33 10 900285
22,5X9,00 175/+-2 281 335 26 10 900286
22,5X9,00 175/+-2 281 335 26 10 900287
22,5X9,00 178/+-2 220 285.75 26 10 900295
22,5X9,00 79/+-2 221 285.75 32.5 37 R22,2 B- 10 900298
22,5X9,00 177,5/+0,5 281 335 26 10 900302
22,5X9,00 eksi 15/-2 281 335 26 10 900314
22,5X9,00 175/+-2 281 335 26 10 900319
22,5X9,00 175/+-2 281 335 26 10 900326
22,5X9,00 175/+-2 221 285.8 26 10 900330
22,5X9,00 0 281 335 26 10 900331
22,5X9,00 178/+2 281 335 26 10 900340
22,5X9,00 133,5/+-2 220 285.75 28.5 10 900341
22,5X9,00 175/+-2 281 335 27 32 R18 B3 10 900355
22,5X9,00 0/+-2 221 275 27 32 R18 A3 8 900359
22,5X9,00 175/+-2 281 335 26 10 900361
22,5X9,00 175/+-2 281 335 27 32 R18 B3 10 900362
22,5X9,00 80/-3 221 275 27 8 900370
22,5X9,00 127/+-2 900901
22,5X9,00 100/-3 900903
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
24,5X8,25 168/+-2 221.5 285.75 31.8 37 R22,2 B- 10 245828
24,5X8,25 168/+-2 220 285.75 26 10 245832
24,5X8,25 168/+-2 220 285.75 26 10 245833
24,5X8,25 120/+-2 245900
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
17,5X5,25 124/+4 161 205 21.5 27 R16 B2 6 525100
17,5X5,25 115/+-2 150 208 32.5 37 R22,2 B- 5 525108
17,5X5,25 131/+-2 161 205 21.5 27 R16 B2 6 525114
17,5X5,25 115/+-2 150 208 32.5 37 R22,2 B- 5 525115
17,5X5,25 129/-4 161 205 21 6 525119
17,5X5,25 120/+-2 161 205 20 6 525123
17,5X6,00 130/+-3 161 205 25.4 31.5 80 B17 6 600100
17,5X6,00 133/+3 176 225 26 32 R18 B33 10 600101
17,5X6,00 127/+3 146 203.2 29 34 R22 B34 5 600102
17,5X6,00 127/+3 161 205 21.5 27 R16 B2 6 600103
17,5X6,00 133/+3 161 205 21.5 27 R16 B2 6 600106
17,5X6,00 128/+3 164 222.25 27 32 R18 B3 6 600108
17,5X6,00 127/+3 164 222.25 32.5 37 R22 B- 6 600109
17,5X6,00 115/+3 146 203.2 32.5 37 R22 B- 5 600112
17,5X6,00 0 161 205 21.5 27 R16 A2 6 600113
17,5X6,00 134/+-2 176 225 26 10 600114
17,5X6,00 eksi 10/+-2 161 205 21.5 27 R16 A2 6 600115
17,5X6,00 115/+3 150 208 32.5 37 R22 B- 5 600118
17,5X6,00 0 161 205 21.5 27 R16 A2 6 600126
17,5X6,00 135/+-3 176 225 27 32 R18 B3 10 600129
17,5X6,00 133/+3 176 225 24 10 600131
17,5X6,00 130/+-3 161 205 21.5 6 600133
17,5X6,00 135/+-2 161 205 21 6 600134
17,5X6,00 115/+3 146 203.2 32.5 37 R22 B- 5 600136
17,5X6,00 135/+-2 161 205 21.5 27 R16 B2 6 600138
17,5X6,00 125/+-2 161 205 21.5 27 R16 B2 6 600139
17,5X6,00 133/+-3 176 225 26 32 R18 B33 10 600140
17,5X6,00 125/+4 161 205 21.5 6 600143
17,5X6,00 133/+-2 176 225 26 10 600145
17,5X6,00 117/+3 164 222.25 32.5 37.5 R22 B- 8 600156
17,5X6,00 135/+3 164 222.25 32.5 37 R22 B- 6 600159
17,5X6,00 129/+-2 202 245.2 21.5 27 R16 B2 6 600166
17,5X6,00 122/+-2 261 300 26 32 R18 A33 içten 10 600170
17,5X6,00 134/+-2 221 275 24 8 600174
17,5X6,00 116/+-2 161 205 21 6 600176
17,5X6,00 124/+-2 176 225 26 32 R18 B33 10 600180
17,5X6,00 127/+3 164 222.25 32.5 37 R22 B- 6 600187
17,5X6,00 125/-3 202 245.2 26 6 600709
17,5X6,00 106/+-2 221 275 27 32 R18 B3 8 600721
17,5X6,00 127/-3 202 245 21.5 27 R16 B2 6 600725
17,5X6,00 35/+-2 161 205 21.5 27 R16 A2 6 600726
17,5X6,00 eksi 45/+-2 161 205 21.5 27 R16 A2 6 600727
17,5X6,00 35/+-2 161 205 21.5 27 R16 B2 6 600728
17,5X6,00 127/+3 164 222.25 32.5 37 R22 B- 6 600729
17,5X6,00 127/+-2 140 190 21 6 600730
17,5X6,00 125/+4 161 205 21 6 600731
17,5X6,00 127/+3 161 205 21.5 27 R16 B2 6 600732
17,5X6,00 125/-2 161 205 21.5 27 R16 B2 6 600734
17,5X6,00 127/+3 146 203.2 29 34 R22 B34 5 600736
17,5X6,00 120/+-2 161 205 21.5 27 R16 B2 6 600737
17,5X6,00 125/+4 161 222.25 21 6 600742
17,5X6,00 116/+-2 176 225 26 32 R18 B33 10 600743
17,5X6,00 108/+-2 176 225 27 32 R18 B3 10 600748
17,5X6,00 35/+-2 133.7 170 17.5 21.5 80 A- 6 600751
17,5X6,00 109,5/+-2 221 275 24 8 600752
17,5X6,00 125/+-2 176 225 26 10 600756
17,5X6,00 133/+-2 176 225 26 32 R18 B33 10 600759
17,5X6,00 125/+4 161 222.25 24 6 600761
17,5X6,00 115/+3 161 205 21.5 27 R16 B2 6 600762
17,5X6,00 131/+-2 164 222.25 32.5 37 R22 B- 6 600764
17,5X6,00 116/+3 176 225 26 32 R18 B33 10 600769
17,5X6,00 93/+3 600900
17,5X6,75 145/+-3 161 205 21.5 27 R16 B2 6 675100
17,5X6,75 145/+-3 176 225 27 32 R18 B3 10 675101
17,5X6,75 145/+-3 176 225 26 32 R18 B33 10 675102
17,5X6,75 141/+-2 221 275 21.5 27 R16 B2 8 675105
17,5X6,75 141/+-2 221 275 24 8 675106
17,5X6,75 141/+-2 221 275 25.4 31.5 80 B17 8 675107
17,5X6,75 140/+-2 202 245.2 21.5 6 675109
17,5X6,75 135,5/+-2 176 225 26 10 675110
17,5X6,75 138/+3 161 205 21.5 27 R16 B2 6 675111
17,5X6,75 135/+3 164 222.25 32.5 37 R22,2 B- 6 675116
17,5X6,75 141/+-2 221 275 24 29 R16 B- 8 675121
17,5X6,75 55/-2 176 225 26 10 675122
17,5X6,75 145/+-3 176 225 24 10 675124
17,5X6,75 0 161 205 21.5 27 R16 A2 6 675128
17,5X6,75 135/+-2 176 225 26 10 675135
17,5X6,75 145/+-3 176 225 26 32 R18 B33 10 675136
17,5X6,75 145/+-3 176 225 25.4 31.5 80 B17 10 675140
17,5X6,75 141/+-2 176 225 26 32 R18 A33 içten 10 675147
17,5X6,75 145/+-3 176 225 26 10 675151
17,5X6,75 125/+-2 161 205 21.5 27 R16 B2 6 675153
17,5X6,75 eksi 12,7/+-1,5 120,95/121,1 165.1 17.4 8 675156
17,5X6,75 eksi 7,8/+-1,5 120,95/121,1 165.1 17.4 8 675157
17,5X6,75 4,8/+-1,5 120,95/121,1 165.1 17.4 8 675158
17,5X6,75 145/+-2 176 225 26 32 R18 B33 10 675168
17,5X6,75 157/+-2 165.1 222.25 31.7 37.7 R22,2 B- 10 675181
17,5X6,75 141/+-2 202 245 21.5 27 R16 B2 6 675184
17,5X6,75 140/+-2 161 205 21.5 6 675186
17,5X6,75 141/+-2 161 205 21.5 27 R16 B2 6 675187
17,5X6,75 135/+-2 176 225 26 32 R18 B33 10 675701
17,5X6,75 142/+-3 221 275 26 8 675703
17,5X6,75 140/+-2 176 225 26 32 R18 B33 10 675705
17,5X6,75 150/+-2 202 245 21.5 27 R16 B2 6 675706
17,5X6,75 142/+-3 221 275 26 8 675734
17,5X6,75 133/+4 176 225 27 32 R18 B3 10 675738
17,5X6,75 0 176 225 26 32 R18 A33 10 675739
17,5X6,75 eksi 12,7/+-1,5 124.5 165.1 17.4 23.8 60 A- 8 675754
17,5X6,75 140/+2 176 225 26 10 675757
17,5X6,75 eksi 38/+-2 152.6 203.2 16.6 23.6 90 B- 8 675759
17,5X6,75 140/+1 221 275 24 8 675768
17,5X6,75 0 221 275 27 32 R18 A3 8 675769
17,5X6,75 135/+-2 176 225 26 32 R18 B33 10 675772
17,5X6,75 75/+2 202 245 21.5 6 675779
17,5X6,75 139,5/+-2 176 225 27 32 R18 A3 içten 10 675790
17,5X6,75 132/+-2 164 222.25 32.5 37.5 R22 B- 6 675795
17,5X6,75 127/+-2 121 165.1 15.9 8 675796
17,5X6,75 0 161 205 21.5 27 R16 A2 6 675810
17,5X6,75 135/+-2 176 225 26 10 675815
17,5X6,75 0 161 205 21.5 6 675816
17,5X6,75 145/+-2 221 275 24 8 675825
17,5X6,75 141/+-2 202 245 21.5 27 R16 B2 6 675831
17,5X6,75 121,5/+-2 281.2 335 21.5 10 675835
17,5X6,75 145/-3 261 300 26 32 R18 B33 10 675838
17,5X6,75 127/+-2 176 225 26 32 R18 B33 10 675843
17,5X6,75 131,5/+-2 176 225 26 32 R18 B33 10 675844
17,5X6,75 0 161 205 21.5 27 R16 A2 6 675847
17,5X6,75 133/-3 176 225 26 10 675848
17,5X6,75 121,5/+-2 221 275 24 8 675851
17,5X6,75 139/+-2 164 222.25 32.5 37 R22 B- 6 675852
17,5X6,75 100/+3 675900
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
5,50JX16 H2 114,5/+-1,5 130 170 21.5 6 550160
5,50JX16 H2 112/+-1,5 161 205 18.5 24 R14 A1 6 550164
5,50KX16 H2 116,5/+1,5-0,5 146 203.2 29 34 R22 B34 5 550174
5,50JX16 H2 110/+2 139 180 16 6 550179
5,50-16 124/+-2 146 203.2 29 35 R18 B- 5 55142
5,50-16 124/+-2 164 222.25 32.5 37 R22 B- 6 55502
5,50-16 127/+-1 164 222.25 32.5 37 R22 B- 6 55514
6,00-16 132/+-2 164 222.25 27 32 R18 B3 6 60113
6,00JX16 H2 120/+1,5 161 205 19 24 R14 B- 6 601601
6,00JX16 H2 132/+1,5 161 205 19 24 R14 B- 6 601602
6,00JX16 H2 132/+1,5 161 205 21 6 601604
6,00JX16 H2 eksi 12/+-1 161.5 205 21.5 27 R16 A2 6 601605
6,00JX16 H2 eksi 12/+-1 161.5 205 21.5 27 R16 A2 6 601606
6,00JX16 H2 50/+-1 133.7 170 17.5 21.5 80 A- 6 601607
6,00JX16 H2 55/+-1 138.8 180 15 6 601608
6,00JX16 H2 105/+1,5 161 205 21.5 27 R16 B2 6 601609
6,00JX16 H2 115/+1,5 161 205 21.5 27 R16 B2 6 601610
6,00JX16 H2 18/+-2 161 205 21.5 27 R16 A2 6 601612
6,00JX16 H2 131/+-1,5 164 222.25 29 34 R22 B- 6 601613
6,00JX16 H2 120/+1,5 161 205 17 6 601615
6,00JX16 H2 45/+-2 90 150 15 6 601616
6,00-16 0 161 205 21.5 27 R16 A2 6 60500
6,50-16 0 161 205 21.5 27 R16 A2 6 65105
6,50-16 0 122 162 21.5 27 R16 A2 6 65115
6,50-16 55/+-2 130 170 21 6 65122
6,50-16 115/+-2 161 205 21 6 65123
6,50-16 101/+-2 130 170 21 6 65124
6,50-16 101/+-2 130 170 21 6 65125
6,50-16 0 190 280 22 12 65613
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
6,0-15 122/+4 176 225 27 32 R18 B3 10 60801
6,5-15 135/+4 176 225 26 10 65155
6,5-15 135/+4 176 225 27 32 R18 B3 10 65157
6,5-15 0 161 205 21.5 27 R16 A2 6 65160
6,5-15 124/+-2 161 205 21.5 27 R16 B2 6 65161
6,5-15 124/+-2 176 225 27 32 R18 B3 10 65164
6,5-15 129/-2 161 205 21.5 27 R16 B2 6 65165
6,5-15 0 161 205 21.5 27 R16 A2 6 65167
6,5-15 140/+2 176 225 27 32 R18 B3 10 65169
7,5-15 155/+-2 176 225 26 10 75155
7,5-15 160/-3 176 225 27 32 R18 B3 10 75160
JANT BOYU OFSET HDS(MM) ET GİRİŞİ MERKEZ DELİK P.C.D CIVATA DELİĞİ ÇAPI (D1) CIVATA DELİĞİ ÇAPI (D2) KÜRESEL RADIUS / AÇI CIVATA DELİK TİPİ CIVATA DELİĞİ NUMARASI JANTSA PARÇA NUMARASI
8,0-24 172/+4 281 335 26 10 80244
8,5X24 180/-3 281 335 26 10 852400
8,5X24 180/-3 281 335 27 32 R18 A3 10 852401
8,5-24 175/+3 281 335 26 10 85258
8,5-24 184/-2 281 335 26 10 85277
8,5-24 185/+2 281 335 26 10 85282
8,5-24 180/+4 281 335 27 32 R18 B3 10 85800
8,5-24 172/+4 281 335 26 10 85801
8,5-24 180/+4 281 335 26 10 85802
8,5-24 175/+-2 281 335 26 10 85806
8,5-24 175/+-2 281 335 26 10 85807
8,5-24 180/+-2 281 335 26 10 85808
TİCARİ
Burada tüm ürünler listelenmemiştir. Bu listede görmediğiniz tüm ürünler için lütfen bizimle irtibata geçiniz.

TARIM

Tüm Ürünler

SANAYİ

Tüm Ürünler

Sizlere daha iyi hizmet sunabilmek için web sitemizde çerezler kullanılmaktadır. Detaylı bilgi için tıklayınız.
